Routine maintenance
75
A
b Press the lock release lever as shown to
release the cartridge color indicated on
the Touchscreen. Remove the cartridge
from the machine.
c Open the new ink cartridge bag for the
color indicated on the Touchscreen, and
then take out the ink cartridge.
d Turn the green release lever on the
orange protective packing (1)
counterclockwise until it clicks to release
the vacuum seal. Then remove the
orange protective packing as shown.
DO NOT touch the cartridge in the area
indicated (2); this can prevent the
machine from detecting the cartridge.
1
2
1
2
To Next Page
