Brother MFC-L8650CDW - Page 191

3-27
Confidential
D
D
C
B
A
9.20
ADF Cover ASSY
9.21
Gear Cover
9.22
Separation Roller
9.23
ADF Separation
Pad Holder
(A4 Model Only)
9.24
ADF Separation Pad/
Separate Support Film
(Legal Model Only)
(Legal Model Only)
9.25 ADF Separation
Spring Holder
9.26 CIS Spacer
9.27 Second side
CIS flat cable/
Second side CIS unit
9.28 ADF Cover/Document
Detection Sensor PCB ASSY/
First Side Document Scanning Position
Sensor PCB ASSY/Second Side Document
Scanning Position Sensor PCB ASSY
(Duplex Scanning Model Only)
9.29 Document
Feed Roller ASSY 2
9.30 Eject Film
9.31 ADF Motor
9.32 Document
Cover ASSY
9.46 Main PCB
ASSY
9.49 Process Drive
Unit/Fuser Drive
Gear Z25
9.55 Paper Eject
ASSY
9.57 Paper Eject
Origin Sensor
9.58 Back Cover
Sensor ASSY
9.51 Develop
Release Drive Unit
9.52 Develop
Release Sensor
PCB ASSY
9.53 Toner/New
Sensor PCB ASSY
9.50 Main Drive
Unit
9.63 MP Paper
Empty Actuator A
ASSY/
MP Paper Empty
Actuator B
9.65 Paper Feed
Unit/Joint Pin
9.67 T1 Paper
Feed Sensor PCB
ASSY
9.64 MP Paper
Empty/Registration
Front Sensor
PCB ASSY
9.66 Registration
Front/Rear Sensor
PCB ASSY
9.47
Laser Unit Flat
Cable/Laser Unit
80/80
5/5
10/10
60/60
5/5
23/23
35/35
10/10 10/10
8/32
10/10
5/5
10/10
5/5
114/114
147/147
25/25
3/3
30/30
8/8
54/54
23/23
15/1522/22
34/34
35/35
38/38
15/15
