Brother MFC-L8650CDW - Duplex Tray

To Next Page

To Previous Page

3-49

Confidential

9.9 Duplex Tray

(1) Remove the two Taptite cup B M3x12 screws and remove the Duplex tray from the Main

body.

Fig. 3-35

Taptite cup B M3x12

Main body

Taptite cup B M3x12

Duplex tray
