Brother MFC-L8650CDW - Joint Film2 (Single-Side Scanning Model Only)

To Next Page

To Previous Page

3-122

Confidential

9.40 Joint Film2 (Single-side Scanning Model Only)

(1) Peel off the double-sided adhesive tape and remove the Joint film2 from the Joint cover top.

Fig. 3-162

Joint film2

Joint cover top
