Brother MFC-L8650CDW

To Next Page

To Previous Page

3-101

Confidential

(5) Remove the Document feed roller ASSY 2 from the Lower ADF chute.

Fig. 3-122

Document feed roller ASSY 2

Lower ADF chute
