(13) Release the Hook and remove the Fuser drive gear Z25 from the Process drive unit.

Fig. 3-207

Harness routing: Refer to “ Laser Unit”, “ Process Drive Unit, Front Cover Sensor,

Main Drive Unit”, “ Develop Release Drive Unit, Develop Release

Sensor PCB ASSY, Toner/New Sensor PCB ASSY”, “ MP Paper

Empty/Registration Front Sensor PCB ASSY”, “ Paper Feed Unit”

Hook

Fuser Drive Gear Z25

Process drive unit
