(13) Release the two Hooks and remove the MP paper empty actuator A ASSY from the MP

upper cover ASSY.

Fig. 3-244

(14) Release the Hook and remove the MP paper empty actuator B from the MP upper cover

ASSY.

Fig. 3-245

Hook

MP paper empty actuator A ASSY

MP upper cover ASSY

MP paper empty actuator A ASSY

MP paper empty actuator B

MP paper empty

actuator B

Hook

MP paper empty actuator B

14a

14b

MP upper cover ASSY

Attach it to the cutouts.
