Brother MFC-L8650CDW Service Manual

5-56
Confidential
1.3.30 Setting by country (Function code 74)
<Function>
This function is used to customize the machine according to language, function settings, and
worker switch settings.
<Operating procedure>
(1) Press the 7 and 4 keys in this order in the initial state of the maintenance mode.
The present spec code is displayed on the LCD.
(2) Enter the desired spec code (fourth digits).
(3) When you press the Mono Start key, the new setting is saved, and “PARAMETER INIT” is
displayed on the LCD. After the setting is saved, the machine returns to the initial state of
the maintenance mode.
<Spec code>
Note:
If there is a pause of more than one minute, the machine will automatically return to the
initial state of the maintenance mode.
MODEL Spec code Spec code (Detail)
DCP-L8400CDN Brazil 0042 --- ---
CEE-General 1004 --- ---
China 0020 --- ---
France/Belgium/Netherlands 1058 Belgium 1008
France 1004
Netherlands 1004
Others 1004
Germany 3004 --- ---
Italy/Iberia 1004 --- ---
Pan-Nordic 1004 --- ---
Switzerland 1004 --- ---
UK 1004 --- ---
DCP-L8450CDW CEE-General 1104 --- ---
France/Belgium/Netherlands 1158 Belgium 1108
France 1104
Netherlands 1104
Others 1104
Germany 3104 --- ---
Italy/Iberia 1104 --- ---
Italy-CONSIP 9104 --- ---
Pan-Nordic 1104 --- ---
Switzerland 1104 --- ---
UK 1104 --- ---
MFC-L8600CDW Australia/New Zealand 0256 Australia 0206
New Zealand 0227
Brazil 0242 --- ---
Canada 0202 --- ---
Gulf 0274 Gulf 0241
South Africa 0224
Turkey 0225
Korea 0244 --- ---
Taiwan 0223 --- ---
U.S.A 0201 --- ---
