8-33 Confidential
8.5.13 Travel Check of the Head/Carriage Unit and Initial Setup Mode (Function code 63)
îš„ Function
This procedure moves the head/carriage unit to the head replacement position (Function code 63 +
*).
It can also enable or disable the initial setup mode when the power is applied at the next time
(Function code 63 + 1 or Function code 63 +3).
îš„ Operating Procedure
MFC620CN/425CN/420CN/410CN/215C/210C and FAX2440C
(1) Press the 6 and 3 keys in this order in the initial stage of the maintenance mode.
The "MAINTENANCE 63" will appear on the LCD.
(2) To make the head/carriage unit travel to the head replacement position
, press the * key.
After completion of head replacement or adjustment jobs, press the Stop/Exit key. The
head/carriage unit returns to the home position where the head/carriage unit will be locked.
(3) To enable or disable the initial setup mode when the power is applied at the next time
, press
the 1 or 3 key, respectively.
If you enable the initial setup mode, wait until the "INIT" appears on the LCD and the
head/carriage unit becomes locked. When the "HEAD LOCKED" appears, turn the power off.
NOTE: Enabling the initial setup mode resets all counts which can be displayed with Function
code 80 (described in Section 8.5.21 "Display of the Equipment's Log") to zero.
If you disable the initial setup mode, the machine displays the "NOT INIT" on the LCD and
returns to the initial stage of the maintenance mode.
DCP315CN/310CN/120C/117C/115C/110C
(1) Enter 6 and 3 in the initial stage of the maintenance mode by using the
and Set keys.*
(*To enter a numerical code on models having no numerical keypad, press the key several times to
display the numerical code to be entered and then press the Set key. Repeat this operation for each
numerical code.)
The "MAINTENANCE 63" will appear on the LCD.
(2) To make the head/carriage unit travel to the head replacement position
, enter * by using the
and Set keys.*
After completion of head replacement or adjustment jobs, press the Stop/Exit key. The
head/carriage unit returns to the home position where the head/carriage unit will be locked.
(3) To enable or disable the initial setup mode when the power is applied at the next time
, enter 1
or 3 by using the
and Set keys, respectively.
If you enable the initial setup mode, wait until the "INIT" appears on the LCD and the
head/carriage unit becomes locked. When the "HEAD LOCKED" appears, turn the power off.
NOTE: Enabling the initial setup mode resets all counts which can be displayed with Function
code 80 (described in Section 8.5.21 "Display of the Equipment's Log") to zero.
If you disable the initial setup mode, the machine displays the "NOT INIT" on the LCD and
returns to the initial stage of the maintenance mode.
