304
GEARCASE – STANDARD ROTATION
SHIFTER, BEARING AND SEAL SERVICING
Push the pin out of the clutch dog . Remove all
parts.
Remove the gear, thrust bearing, and thru st
washer from the shift housing.
Remove th e shif t lever pin from the ho using.
Remove shif t shaf t, crad le an d shif t leve r. Move
shifter detent as needed to help ease re moval of
parts.
Wrap the housing with a shop cloth to ca tch ball
and spring. Rotate the sh ifter detent 90° in either
direction, then pull the detent out of the housing.
Remove the detent ball and spring.
Remove needle bearings from bearing housing for
cleaning and inspection.
1. Pin 006888
1. Gear
2. Thrust bearing
3. Thrust washer
006889
1. Shift lever pin
2. Shift shaft
3. Cradle
4. Shift lever
5. Shifter detent
006890
A WARNING
Wear safety glasse s to avoid personal
injury. Th e dete nt ball and s pring and
come out with great force.
1. Shifter detent
2. Ball and spring
006891
