305
GEARCASE – STANDARD ROTATION
SHIFTER, BEARING AND SEAL SERVICING
13
Shift Housing Assembly
IMPORTANT: Clean and inspect all parts before
beginning assembly procedures. Replace any
damaged parts.
Lightly coat the detent ball and spring with Needle
Bearing grease. In sert the spring in th e ho using,
then the ball.
Insert shifter detent at 90° a ngle into the housing
as shown, while depressing t he ba ll and spring
with a suitable tool. Once the shifter detent is past
the ball, remove th e too l an d po sition d etent to
engage NEUTRAL position.
Thoroughly grease 25 needle bearings wit h Nee-
dle Bearing grease and place in the bearing case.
With shif ter detent in NEUTRAL, in stall arms of
shift le ver into dete nt slot s. Align the pivot holes
and insert th e re taining p in. Push shif ter detent
down.
Rest the cradle on the shift shaft.
006899
006900
006901
1. Shifter detent
2. Shift lever
3. Pin, shift lever
006902
1. Cradle
2. Shift shaft
004512
