4 Product Description of the ICS
4.1 Scope of Application
The ICS consists of two separate devices. The Ground Pad Module (GPM) thereby forms that part connected to
the power supply network, which transmits the energy to the Car Pad Module (CPM) integrated in the vehicle. The
communication between GPM and CPM is automated and takes place via WLAN.
NOTE
Note:
The Car Pad Modules of the possible variants from chapter
3.1
function with all Ground Pad Modules
(GPM) of the ICS.
4.1.1 User Description
The user group of the system ICS includes all persons who are able to operate a vehicle. The user of the system is
responsible for the observance of and compliance with the safety instructions contained in this user manual. The
user is also responsible, that persons in his environment, in particular all persons who come into contact with the
ICS, are knowledgeable of and familiar with the safety instructions in this user manual. The user must indicate
possible hazards due to the ICS to other persons. He must thereby ensure, that individual, particularly endangered
persons, e.g. children and disabled persons, have understood the safety instructions – or on the other hand
ensure, that access to the ICS is not possible for these persons.
All activities that concern the installation, commissioning and deinstallation / disposal of the ICS may only be
performed by specialist personnel. The specialist personnel or qualified electricians must satisfy the specialist
requirements specified in chapter 12.3.
4.1.2 Health Hazards
WARNING
Risk of injury from electromagnetic field!
With inductive charging an electromagnetic field is generated under the vehicle.
Cardiac pacemakers and medical implants can be affected.
Do not reach underneath the vehicle or perform maintenance work during the charging process.
Operation Manual
Inductive Charging System
ICS115
12
