Brusa ICS115 - 12.2 Technical Data

12.2 Technical Data
BASIC DATA ICS VALUE UNIT
Total weight approx. 52 kg
Rated input voltage (single-phase L1/N) 200 – 240 V
AC
Rated input voltage (two-phase L1/L2) 100 – 120 V
AC
Rated input frequency 50 – 60 Hz
Maximum input current 16 A
rms
Max. input power 3600 W
Charging voltage 200 – 440 V
DC
Max. charging current 12 A
DC
Charging capacity 500 – 3200 W
Energy transmission frequency 81.38 – 90 kHz
Duration of a charging process Dependent on type of vehicle
Transmission frequency WLAN (ISM Band) 2.412 – 2.462 GHz
Max. transmit power WLAN 100 mW
Transmission frequency positioning 125 kHz
LV-wiring system CPM 9 – 16 V
DC
LV-wiring system max. voltage CPM (device destruction) 27 V
DC
IP protection class IP6K9K, IP65 -
Insulation class acc. EN 61140 Protection class I -
BASIC MECHANICAL DATA MIN MAX UNIT
Height above ground GPM 0 0 mm
Height above ground CPM 100 160 mm
43
Operation Manual
Inductive Charging System
ICS115
