12 Annex A1
12.1 Technical Specifications of the ICS
12.1.1 Emissions
Table 1: Emissions
PARAMETER CHARACTERISTIC VALUE UNIT
Max. magnetic flux density between GPM and CPM 7*10
-3
T
Magnetic flux density of the GPM at vehicle limitation 4.6*10
-6
T
WLAN-Signal
- Frequency
2.4
GHz
- Max. transmit power 19 dBm
79 mW
Positioning signal
- Frequency s
- Max. radiated magnetic field strength at 125 kHz
125
17.5
kHz
dBµA/m
12.1.2 Dimensions and Center of Gravity
12.1.2.1 Dimensions GPM [mm]
Operation Manual
Inductive Charging System
ICS115
