12.5.7 Planning the Assembly and Installation of the ICS
Planning the assembly and installation of the CPM, see Annex 12.7.4.
12.5.7.1 Planning the Installation of the GPM
WORK STEP ILLUSTRATION / OTHER INFO
Determine the installation position of the
GPM.
Please note, that certain information must be obtained:
Dimensions of the GPM (ICS User Manual), position of the CPM
installed in the vehicle, request of the user about preferred parking
position of the target vehicle, check of the installation possibility
(solid ground).
Ensure the availability of the GPM for the
installation work step.
Take into consideration the ordering- and delivery times for the
Ensure the availability of the auxiliary
material and the information from the user
manual, to be able to undertake the
installation of the GPM and if necessary be
able to check the correct installation. Make
sure, that the space requirement for the
installation is covered.
Note the use of the respective auxiliary material, that is
ired for the GPM during the installation (see installation
instructions of the vehicle manufacturer), e.g. cable required (note
length!) for the connection of the GPM to the power supply and
auxiliary material for the professional laying of the cable (floo
r-
mounted duct or similar).
Make sure, that all information required for
the installation of the GPM is prepared for
the installation and is available during the
installation.
Note information- and communication channels.
12.5.8 Transport and Storage
12.5.8.1 Transport and Storage of the ICS
CAUTION
Caution during transport and storage of the ICS!
Note the technical specifications of the ICS, e.g. weight and center of gravity! Please note, that with
careless handling of the CPM, injuries are possible: injuries on ICS or packaging, as well as injuries
through allowing the ICS to fall (in packaging)!
Operation Manual
Inductive Charging System
ICS115
52
