17
exposed to the elements. The Damper Control Module (and zone
dampers) may be installed in any area where the temperature remains
between -4°F to 158°F (-20°C to 70°C), and there is no condensation.
The cover must be installed to prevent damage from other sources. Do
not locate where it will be accessible to children. It may be mounted in
either vertical or horizontal position. Remember that wiring access is
likely the most important consideration.
4.5. Decorative Trim Plate
Sold separately, a thin decorative trim plate is available to hide any
marks/screw holes left from the previous thermostat. The trim plate is
captured between the backplate and the system control. Align the trim
plate around the backplate, and snap on the system control.
NOTE: Once the Evolution Connex Control is secured to wall with the
backplate assembly (snapped together), care must be taken not to bend or
break the interlocking tabs when removing.
4.5.1. Mounting
First become familiar with all plastic assembly pieces shown on the
following page. The Evolution Connex Control will snap together with
the standard backplate supplied with the wall control. Attach backplate
CAUTION
!
PERSONAL INJURY HAZARD
Failure to follow this caution may result in personal injury.
To prevent possible damage to the Damper Control Module, DO
NOT mount on plenum, ductwork, or flush against furnace or
fan coil.
