Buderus Logamatic 2107 User Manual

Using your controls
5
Logamatic 2107 controls - We reserve the right to make any changes due to technical modifications.14
5 Using your controls
You can set your heating system via your Logamatic 2107 controls. The clearly
arranged controls make it very easy to use.
Controls on the Logamatic 2107 controls
Fig. 4 Controls on the Logamatic 2107 controls
Item 1: Manual reset high limit (STB)
Item 2: Boiler water thermostat
Item 3: Fuse (10 Amp)
Item 4: Switch for Automatic mode, Emergency mode
Item 5: ON/OFF switch
Item 6: Keys for basic functions
Item 7: Dial
Item 8: Keys for extended functions
Item 9: Display
Item 10: Flap
160
AUT
180
140
120
160
AUT
180
140
120
1
2
3
4
5
7
6
9
8
10
AUTOMATIC
11.15am
69

Buderus Logamatic 2107 Specifications

General

Category	Control Systems
Type	Heating Control Unit
Voltage	230 V
Frequency	50 Hz
Protection class	IP20
Ambient temperature	0°C
Application	Heating systems
