Basic functions
6
Logamatic 2107 controls - We reserve the right to make any changes due to technical modifications.26
6.6 Setting the DHW temperature
The Logamatic 2107 controls allows you to heat the DHW in an energy-
conscious manner. For this purpose, the DHW heating is equipped with a timer.
You can switch on the DHW heating by setting the desired temperature for the
domestic hot water. To save energy, DHW heating is switched off in night mode.
The DHW heating is set at the factory to "DHW AUTO" (automatic mode).
In this setting, the DHW heating starts 30 minutes before one of the two heating
zone switches to normal heating mode (day mode) and ends as soon as both
heating zones are in setback heating mode (night mode) with timer.
The DHW heating is set at the factory to 140°F (60°C) for automatic mode.
AUTOMATIC
11.15am
71
Fig. 10 Example: DHW heating
Heating circuit 1
Heating circuit 2
DHW heating
8.00am 11.00pm
11.00pm
4.00am
3.30am
11.00pm
Day mode
Day mode
30 minutes
USER NOTE
If a recirculation pump is installed for the DHW, it will be activated at the same
time as the DHW heating.
