BFU remote control
8
Logamatic 2107 controls - We reserve the right to make any changes due to technical modifications.42
8.3 Setback heating mode (night mode)
The setback heating mode is set as a temperature
differential with respect to the normal heating mode.
This setting should be made by your heating contractor
when the system is commissioned.
The setting range is 34 – 50°F (1 – 10°C).
The factory default is 7°F (4°C).
Example
Dial set to 70°F (21°C) daytime room temperature.
Set temperature differential 7°F (4°C).
This gives a night-time room temperature of 63°F
(17°C).
8.4 Key functions
The keys on the remote control can be used to set three
different operating modes:
– Automatic mode
– Setback heating mode (night mode)
– Normal heating mode (day mode)
Fig. 12 Remote control
Item 1: "WWSD" LED
Item 2: "Day mode" key
Item 3: "AUT" key
Item 4: "Night mode" key
Item 5: Dial
1
2
3
4
5
