4-10 2003 Buell P3: Fuel System
HOME
ROLLOVER VALVE
NOTE
See Figure 4-6. When the vehicle is upright the check ball
holds the post to one side allowing hydrocarbon vapors to be
released into the atmosphere or into a charcoal canister (Cal-
ifornia). When the vehicle is tipped, the check ball moves
away from the post, which is spring loaded, allowing the post
to seal the opening preventing loss of gasoline through the
vent tube.
Removal
11WARNING1WARNING
Gasoline is extremely flammable and highly explosive.
When servicing the fuel system, do not smoke or allow
open flame or sparks in the vicinity. Inadequate safety
precautions could result in death or serious injury.
1. Remove seat. Depress latch at bottom and pull seat up
and back to remove. See 2.28 SEAT.
11WARNING1WARNING
To protect against shock and accidental start-up of vehi-
cle, disconnect the negative battery cable before pro-
ceeding. Inadequate safety precautions could result in
death or serious injury.
2. Unthread bolt and remove battery negative cable (black)
from battery negative (-) terminal.
3. Drain fuel tank. See 1.20 FUEL SUPPLY VALVE AND
FILTER STRAINER.
4. Remove fuel filler cap from tank.
Figure 4-6. Rollover Valve
a0177x4x
1. Post
2. Check ball
3. Gas
1
2
3
