12 - 1110
DIGITAL INDUSTRIAL CONTROLLER
english
The following output signals are configurable (cf. Sections 5.7 and 6.5.4):
2-point PWM signal (PWM: Pulse width modulation)
3-point PWM signal
3-point step signal
3-point step signal with external feedback (position control)
Electrical data of the relay AC DC
Max. switched voltage 250 V 300 V
Max. switched current 5A 5A
Max. switched power 1250 VA 100 W at 24V, 30 W at 250V
Binary output Terminals 21 and 22
max. load current: 20 mA
Configurable line of action (not inverted / inverted):
Logical value Output not inverted inverted
0 high resistance inactive active
1 17.5 ... 24 V active inactive
Configurable functions:
Signal:
Alarm has occurred
Signal:
Error has occurred
Signal:
MANUALmode
Outputs for alarms
2 relays with one potential free changeover contact and internal connected bose
(see connection diagram):
Relay 3 Terminals 1, 2 and 3
Relay 4 Terminals 3, 4 and 5
Configurable alarms:
Alarm, absolute
Alarm, relative
Alarm, ratio
Electrical data of the relay AC DC
Max. switched voltage 250 V 300 V
Max. switched current 5A 5A
Max. switched power 1250 VA 100 W at 24V, 30 W at 250V
