1110 - 11
DIGITAL INDUSTRIAL CONTROLLER
english
The following output configurations are available:
Controller output for continuous signals
• Output for standard signal 0 ... 10 V Terminals 33 and 34
max. load current: 5 mA
Accuracy: 0,5 %
• Output for standard signal 0 (4) ... 20 mA Terminals 32 and 33
max. load resistance: 600 Ω
Accuracy: 0,5 %
Controller outputs for discontinuous signals
2 relays with one potential free changeover contact each:
Relay 1 Terminals 7, 8 and 9
Relay 2 Terminals 10, 11 and 12
4.4 Signal outputs
Controller output
• Input for the connection of a potentiometer Terminals 19, 20 and 27
for position feedback (1 ... 10 kΩ)
for position regulation
• Binary inputs Terminals 25 and 26
Input resistance: > 25 kΩ
Configurable line of action:
Logical value Voltage not inverted inverted
0 0 ... 4,5 V nactive active
1 13 ... 35 V active inactive
Configurable functions:
• Changeover between manual and automatic mode
• Changeover between external and internal setpoint *)
• Triggering alarms
• Safety value output
*) Available only if controller input 2 has been configured for an external setpoint.
