In total, the main menu of the configuration level embraces the following options:
Structure: ` Definition of the controller structure
` For cascade control
- Definition of the set-point limits of the main controller
` For ratio control
- Definition of the display range for the ratio value
- Setting the set-value limits
- Defining the alarm mode
- Defining the alarm limits for the ratio value
Input 1: • Defining the input signal type
• Decision to include the root function
• Scaling definitions
• Definition of alarm mode and alarm limits
• Dimensioning the input filter
• Setting the setpoint limits
Input 2: • Defining the input signal type
• Decision to include the root function
• Scaling definitions
• Dimensioning the input filter
• In the case of feed forward control: Setting the parameters of the
PDT1 element (function block 26 in Figure 8)
Controller: • Setting controller parameters
Output: • Defining the output signal type
Safety: • Setting the safety value for the manipulated variable.
This manipulated variable is output in the event of an internal
error, an error at the controller input or when the binary input is
active (function: safety).
Adaption: • Selection of various adaption algorithms
Options: • Selection of the language
` Binary input affiliation
` Binary output affiliation
` Setting the ramp
` Defining the set-point tracking
(jolt-free switchover from MANUAL to AUTO)
` Selection of the display layout in row 2
` Input of a security code
When configuring, a specific controller structure must always be defined first using
the Structure menu. The other menus then relate to the selected menu structure.
6.5.2 Main menu of the configuration level
