1110 - 59
DIGITAL INDUSTRIAL CONTROLLER
english
Td:
Derivative action time
Adjustment range: 0.0 ≤ Td ≤ 9999 (in sec.)
With the setting 0, the D-portion of the controller is switched off
(P or PI controller)
Pdb:
Dead zone around the setpoint.
Inside the dead zone the PID-controller does not react on changes
of the process value.
Adjustment range: 0.001 ≤ Pdb ≤ 10 (in %)
(refers to the scaling range P1h,P1l)
CO0:
Controller’s operating point
Adjustment range: COl ≤ CO0 ≤ COh (in %)
(with reference to the regulated variable)
Sub-menu of the main menu option
Controller / Controller 2
RPar 2
Controller parameter of the single controller or
Controller parameter of the subordinate controller in a cascade control
Kp1:
Proportional action coefficient 1 / Gain
Adjustment range: 0.001 ≤ Kp1 ≤ 999.9
(In the case of a 3-point PWM signal, Kp1 refers only
to the output relay 1(heating))
Kp2:
Proportional action coefficient 2 / Gain
Adjustment range: 0.001 ≤ Kp2 ≤ 999.9
(Kp2 applies only to 3-point PWM signals and refers to the output
relay 2 (cooling)
Tr :
Reset time
Adjustment range: 0.4 ≤ Tr ≤ 9999 (in sec.)
With the setting 9999, the I-portion of the controller is switched off
(P or PD controller)
Td:
Derivative action time
Adjustment range: 0.0 ≤ Td ≤ 9999 (in sec.)
With the setting 0, the D-portion of the controller is switched off
(P or PI controller)
Pdb:
Dead zone around the setpoint.
Inside the dead zone the PID-controller does not react on changes
of the process value.
Adjustment range: 0.001 ≤ Pdb ≤ 10 (in %)
(Refers to the scaling range P1h, P1l for
single controllers and P2h, P2l for cascade
controller)
