2-point PWM
(2-point PWM signal)
Period
T+:
Period of the PWM signal
(refers to relay 1)
Adjustment range: 1 ≤ T+ ≤ 999,9 (in sec.)
Manipulated variable limiting
COh:
High manipulated variable limit
Adjustment range: COl ≤ COh ≤ 100 (in %, with reference to
the time period of the PWM Output T+)
COl:
Low manipulated variable limit
Adjustment range: 0 ≤ COl ≤ COh (in %, with reference to
the time period of the PWM Output T+)
The upper manipulated value limit determines the maximum switch-on time, and the
lower regulated value limit the minimum switch-on time of the Output Relay 1. The
entry of the switch-on time is made as a percentage of the time period.
Line of action
inv: no
The output operates with a positive line of action
inv: yes
The output operates with a negative line of action
Pulse output
This function allows you to trigger a pulse valve.
(Relay 1 controls the pickup winding, while relay 2 controls the dropout winding)
Imp: no
Pulse valve is not used
Imp: yes
Pulse valve is used
3-point PWM
(3-point PWM signal)
Period
T+:
Period of the PWM signal for „Heating“ (Relay 1)
Adjustment range: 1 ≤ T+ ≤ 999.9 (in sec.)
T- :
Period of the PWM signal for „Cooling“ (Relay 1)
Adjustment range: 1 ≤ T- ≤ 999.9 (in sec.)
To Next Page
