Do not use the Type 8605 outdoors and avoid heat sources which may result in the permitted temperature •
range to be exceeded.
Power supply 12...24V DC ± 10%
Residual ripple 5 %
Power consumption ca. 1 W
Output current (on the valve) max. 2 A
Operating temperature -10 ... 60º C / 14 ...140ºF
Interference resistance to EN50082-2
Emission to EN50081-2
Current range, depending
on the version for valves 40 ... 220 mA,
200 ... 1000 mA,
500 ... 2000 mA
Voltage (0 ... 5, 0 ... 10 V) input impedance > 20 kW
Current (0 ...20, 4 ... 20 mA) input impedance <200 W
Degree of protection IP40 (DIN EN 60529)
Materials Polyamide / PBT
Dimensions LxBxH: 97x27x57 mm
Degree of protection IP65 (DIN EN 60529)
Materials Polyamide / PC
Dimensions LxBxH: 70x32x42.5 mm
