The controlled coil current cannot follow changes in the input signal at any random speed.
Different sets of control parameters are stored for the internal current control. The controller dynamics can
therefore be set in three discrete steps between:
very fast control with the probably occurrence of overswing behavior and •
slow control with a guaranteed elimination of overswing.•
Set 1: slow
......
Set 3: fast
PArA (Parameter) - Controller settingFigure 23:
Setting of the bus address when using the serial interface (0 to 31).
Addr (Address) - InterfacesFigure 24:
