Burkert 8693 - Default Chapter; Table of Contents

3
1 THE QUICKSTART ................................................................ 4
1.1 Denitionoftheterm‚Device‘ ..................................... 4
1.2 Symbols
....................................................................... 5
2 AUTHORIZED USE ............................................................... 5
3 BASIC SAFETY INSTRUCTIONS .......................................... 6
4 GENERAL INFORMATION .................................................... 7
4.1 Contact address .......................................................... 7
4.2 Warranty ...................................................................... 7
4.3 InformationontheInternet .......................................... 7
5 SYSTEM DESCRIPTION ....................................................... 7
5.1 Functions ..................................................................... 8
6 TECHNICAL DATA ................................................................. 9
6.1 Conformity
................................................................... 9
6.2 Standards .................................................................... 9
6.3 Licenses ...................................................................... 9
6.4 Operating conditions ................................................... 9
6.5 Typelabel ................................................................. 10
6.6 MechanischeDaten ................................................... 10
6.7 Pneumaticdata ......................................................... 10
6.8 Electrical data ............................................................ 11
7 OPERATION ........................................................................ 12
7.1 Descriptionoftheoperatinganddisplayelements ... 12
7.2 Functionofthekeys .................................................... 13
8 OPERATING STATES .......................................................... 14
8.1 Changingtheoperatingstate .................................... 14
8.2 DisplaysintheAUTOMATICoperatingstate .............. 15
8.3 Mastercode ............................................................... 16
9 OPERATING LEVELS .......................................................... 16
9.1 Switchingbetweentheoperatinglevels .................... 16
10 INSTALLATION .................................................................... 17
10.1 InstallationofdevicesfortheExarea .......................... 17
10.2 Safetyinstructions ..................................................... 17
10.3 Installationonprocessvalves,types2103,2300
and 2301 ....................................................................... 17
10.4 Installationonprocessvalves,series26xxand27xx.. 19
10.5 Pneumaticconnection ............................................... 21
11 ELECTRICAL INSTALLATION ............................................. 22
11.1 Safetyinstructions ..................................................... 22
11.2 Electricalinstallationwithcircularplug-inconnector 23
11.3 Electricalinstallationwithcablegland ...................... 25
12 START-UP ............................................................................ 28
12.1 Safetyinstructions ..................................................... 28
12.2 Start-uptype8692 .................................................... 28
12.3 Start-uptype8693 .................................................... 30
13 ETHERNET/IP,PROFINETANDMODBUSTCP ................ 32
13.1 Electrical installation .................................................. 32
13.2 ViewFieldbusconnection ........................................ 33
13.5 Bus status display ..................................................... 34
Contents
english
Type 8692, 8693 REV.2
