Burkert 8693 - OPERATING MODES; Operating state; AUTOMATIC Operating State for Type 8692

35
büS OPTION
13.5.1 BUS.COMM – Settings on type 8692, 8693
SetthefollowingmenuoptionsintheBUS.COMMmenufor
start-upoftheEtherNetversion:
BUS FAIL
Activate or deactivate approach of the
safety position
Selection
SafePos o
–Theactuatorremainsinthe
positionwhichcorrespondstothe
set-pointvaluelasttransferred
(defaultsetting).
Selection
SafePos on
– Ifthereisafaultinthebuscom-
munication,thebehaviorofthe
actuatordependsontheactivation
oftheSAFEPOSauxiliaryfunction.
Seechapter“16.1.13SAFEPOS–
Inputtingthesafetyposition”.
SAFEPOSactivated: Theactuatormovestothesafety
positionwhichisspeciedinthe
SAFEPOSauxiliaryfunction.
SAFEPOSdeactivated: Theactuatormovestothesafety
endpositionwhichitwould
assumeiftheelectricaland
pneumaticauxiliarypowerfailed.
Seechapter“10.9Safetyend
positionsafterfailureofthe
electricalorpneumaticauxiliary
power”
14 büS OPTION
14.1 Electrical installation
Procedure:
→ Connecttype8692,8693accordingtothetables.
Asetscrewwithnutislocatedontheelectricalconnection
housingforconnectionofthetechnicalground.
→ Connectsetscrewtoasuitablegroundingpoint.Toguarantee
electromagneticcompatibility(EMC),ensurethatthecableis
asshortaspossible(max.30cm,Ø1.5mm
2
).
Whentheoperatingvoltageisapplied,type8692,8693is
operating.
→ Nowmaketherequiredbasicsettingsandadjustmentsfor
thepositioncontroller/processcontroller.See
chapter“12Start-up”.
14.2 Denition
büSisaeldbuswhichisbasedonCANopenwithadditional
functionalityfornetworkingseveraldevices.
english
Type 8692, 8693 REV.2
