124
Key
No.
Description
(Quantity) Part Number
ALP080 ALP105 ALP150 ALP210 ALP285 ALP399 ALP500
110 Vent Elbow w/Flue Sensor Port 102878-01 N/A
111 Rear Air Box 102867-01 N/A
112 Bottom Securing Bracket 102870-01 N/A
113 Hanging Bracket, Boiler 102868-01 N/A
114 Hanging Bracket, Wall 102869-01 N/A
115 Air Collar Plate Assembly 102871-01 N/A
116 Air Collar Plate Gasket 102876-01 N/A
117 Access Panel, Rear Air Box 102873-01 N/A
118 Horizontal Strip Gasket (2) 102875-01 N/A
119 Vertical Strip Gasket (2) 102874-01 N/A
120 Access Panel Gasket 102877-01 N/A
1/4-20 x 5/8 Hex Head Cap Screw (Not Shown) (4) 80861312 N/A
1/4-20 Hex Nut w/Lock (Not Shown) (4) 80860456 N/A
Sheet Metal Screw, #8 x 1/2”, Black Oxide (Not Shown) (18) 80860061 N/A
3” Female x 4” Female Vent Pipe Reducer (Not Shown) (1) 103008-01 N/A
XV. Repair Parts (continued)
