6
I. Product Description, Specications and Dimensional Data
Alpine™ Series boilers are condensing high efciency
gas-red direct vent hot water boilers designed for use
in forced hot water space or space heating with indirect
domestic hot water heating systems, where supply water
temperature does not exceed 210°F. These boilers have
special coil type stainless steel heat exchangers, constructed,
tested and stamped per Section IV ‘Heating Boilers’ of
ASME Boiler and Pressure Vessel Code, which provide a
maximum heat transfer and simultaneous protection against
ue gas product corrosion. These boilers are not designed
for use in gravity hot water space heating systems or
systems containing signicant amount of dissolved oxygen
(swimming pool water heating, direct domestic hot water
heating, etc.).
Dimension
Boiler Model
ALP080
(1)
ALP105
(1)
ALP150
(1)
ALP210
(1)
ALP285
(2)
ALP399
(2)
ALP500
(2)
A - Inch
(mm)
12-9/16
(320)
14
(356)
19-11/16
(500)
23-15/16
(608)
21-13/16
(554)
28-7/8
(734)
44-7/8
(1140)
B - Inch
(mm)
5-5/8
(142)
5-13/16
(147)
7-5/16
(185)
6-3/16
(157)
22-1/8
(562)
C - Inch
(mm)
7-5/16
(186)
14-1/8
(358)
13-1/16
(332)
29
(737)
D - Inch
(mm)
9-5/16
(237)
10-3/4
(273)
16-7/16
(417)
17-1/8
(435)
18
(456)
23-3/4
(602)
39-11/16
(1008)
E - Inch
(mm)
5-15/16
(151)
12-1/4
(312)
15-13/16
(402)
29-3/8
(752)
Gas Inlet F
(FPT)
1/2” 3/4” 3/4” 3/4”
Return G
(FPT)
1” 1-1/4” 1-1/2”
Supply H
(FPT)
1” 1-1/4” 1-1/2”
Condensate Drain J *
* Factory Provided Socket End Compression Pipe Joining Clamp
for 3/4” Schedule 40 PVC Pipe
Boiler Two-Pipe
CPVC/PVC Vent Connector
(Figs. 1A, 1C, 1D) - Inch
3 x 3 3 x 4 4 x 4
Boiler
CPVC Vent Connector/Pipe
(Fig. 1B) - Inch
3” N/A N/A N/A
Boiler Inlet Air Connector
(Fig. 1B) - Inch
3” 3” 4” 4” N/A N/A N/A
Approx. Shipping Weight
(LBS)
137 155 182 206 256 304 350
Table 1: Dimensional Data (See Figures 1A, 1B, 1C & 1D)
NOTES:
(1)
- These boiler models available as either Floor mounted (sufx F) or, Wall mounted (sufx W).
(2)
- These boiler models available as Floor mounted (sufx F) only.
