Burnham ALPINE - Appendix C - Tables

129
Appendix B - Tables
Table
Number
Page
Number
Description
Section I - Product Description, Specications & Dimensional Data
Table 1 6 Dimensional Data (See Figures 1A, 1B, 1C & 1D)
Table 2A 11 Rating Data - Models ALP080 thru ALP500 (0 to 2000 Feet Elevation Above Sea Level)
Table 2B 11 Rating Data - Models ALP080 thru ALP500 (2001 to 7000 Feet Elevation Above Sea Level)
Table 2C 12 Rating Data - Models ALP150 thru ALP285 (7001 to 10,000 Feet Elevation Above Sea Level)
Section IV - Venting
Table 3 19 Vent/Combustion Air System Options
Table 4A 21 CPVC/PVC Vent & Air Intake Components Included With Boiler
Table 4B 21
CPVC/PVC Vent & Air Intake Components (Installer Provided) required for Optional Vertical (Roof)
Termination
Table 4C 22
CPVC/PVC Vent & Air Intake Components (Installer Provided) required for Optional Horizontal
(Snorkel) Termination
Table 5 22 Clearances from Vent Piping to Combustible Material
Table 6 22 Vent System and Combustion Air System Components
Table 7 24
Vent/Combustion Air Pipe Length – Two-Pipe Direct Vent System Options (CPVC PVC and Stain-
less Steel/PVC or Galvanized Steel)
Table 8A 30 U.S. Boiler Vent System Components (Stainless Steel)
Table 8B 30 Alternate Vent Systems and Vent Components (Stainless Steel)
Table 9 31 Concentric Vent Length
Table 10 31 Concentric Vent Components
Section VI - Water Piping and Trim
Table 11 43 Flow Range Requirement Through Boiler
Table 2A 44
Recommended Circulator Models for Alpine (ALP) Boilers Based on 25°F Temperature Differential
and Up to 75 ft. Equivalent Length Near-Boiler Piping - Space Heating Circulator
Table 13 45 Fitting & Valve Equivalent Length
Section VII - Gas Piping
Table 14A 50
Maximum Capacity of Schedule 40 Black Pipe in CFH* (Natural Gas) For Gas Pressures of 0.5
psig or Less
Table 14B 51
Maximum Capacity of Schedule 40 Black Pipe in CFH* (LP Gas) For Gas Pressures of 0.5 psig or
Less
Table 15 51 Equivalent Length of Standard Pipe Fittings & Valves
Table 16 52 Specic Gravity Correction Factors
Table 17 52 Min./Max. Pressure Ratings
Section VIII - Electrical
Table 18 55 Boiler Current Draw
Section IX - Boiler Stacking
Table 19 61 Alpine (ALP) Boiler Model Stacking Combinations
Section X - Modular Installation
Table 20 66 Modular Boiler Water Manifold Sizing
Table 21 71 & 72
Recommended Circulator Models for Alpine (ALP) Boilers and Alliance SL Indirect Water Heaters
Installed as Part of Near-Boiler Piping Up to 75 Ft. Equivalent Length - Indirect Water Heater
Circulator
Table 22 79 Sequence Master Priority
