Burnham ALPINE - CPVC;PVC Venting

21
Table 4A: CPVC/PVC Vent & Air Intake Components Included With Boiler
Vent & Air Intake Components
Part
Number
Quantity
ALP080 & A
LP105
Standard Termination
Vent Kit
(P/N
102189-01)
includes
ALP150 & ALP210
Standard Termination
Vent Kit
(P/N 102189-02)
includes
ALP285 thru ALP500
Standard Termination
Vent Kit
(P/N 102189-03)
includes
3” Schedule 40 PVC Tee (Vent & Air Intake
Terminals)
102190-01 2 1 N/A
4” Schedule 40 PVC Tee (Vent & Air Intake
Terminals)
102190-02 N/A 1 2
3” Stainless Steel Rodent Screen 102191-01 2 1 N/A
4” Stainless Steel Rodent Screen 102191-02 N/A 1 2
3” x 30” Schedule 40 CPVC Pipe 102193-01 1 1 N/A
4” x 30” Schedule 40 CPVC Pipe 102193-02 N/A N/A 1
3” Schedule 80 CPVC 90° Elbow 102192-01 1 1 1
4” Schedule 80 CPVC 90° Elbow 102192-02 N/A N/A 1
4 oz. Bottle of Transition Cement 102195-01 1 1 1
4 oz. Bottle of Primer 102194-01 1 1 1
3" Vent/3" Combustion Air CPVC/PVC
Connector
102183-01 1 N/A N/A
3" Vent/4" Combustion Air CPVC/PVC
Connector
102183-02 N/A 1 N/A
4" Vent/4" Combustion Air CPVC/PVC
Connector
102183-03 N/A N/A 1
3" Vent/3" Combustion Air CPVC/PVC
Connector Gasket
102185-01 1 N/A N/A
4" Vent/4" Combustion Air CPVC/PVC
Connector Gasket
102185-02 N/A 1 1
Vent Components
Part
Number
Quantity
ALP080 & A
LP105
Vertical (Roof)
Termination
ALP150 & A
LP210
Vertical (Roof)
Termination
ALP285 thru ALP500
Vertical (Roof)
Termination
3" Schedule 40 PVC Coupler
N/A
Supplied by
Others
1 N/A N/A
4" Schedule 40 PVC Coupler N/A 1 1
3" Schedule 40 PVC 90° Elbow
2 N/A N/A
4" Schedule 40 PVC 90° Elbow
N/A 2 2
3" Schedule 40 CPVC Pipe x ½ ft. min. horizontal run
1
N/A
N/A
4" Schedule 40 CPVC Pipe x ½ ft. min. horizontal run
N/A 1 1
Table 4B: CPVC/PVC Vent & Air Intake Components (Installer Provided) required for Optional Vertical
(Roof) Termination
B. CPVC/PVC Venting
WARNING
All CPVC vent components (supplied with boiler)
must be used for near-boiler vent piping before
transitioning to Schedule 40 PVC pipe (ASTM
2665) components for remainder of vent system.
WARNING
CPVC vent components must be used within any
interior space where air cannot circulate freely,
such as air inside a stud wall, and in any boiler
closet.
WARNING
When using the CPVC/PVC vent options, the use
of CPVC is required when venting in vertical or
horizontal chase ways.
1. Components and Length Restrictions
a. See
Table 4A for CPVC/PVC Vent & Air Intake
Components included with boiler, Table 4B for
CPVC/PVC Vent and Air Intake Components
(Installer Provided) required for Optional
Vertical (Roof) Termination and Table 4C for
CPVC/PVC Vent and Air Intake Components
(Installer Provided) required for Optional
Horizontal (Snorkel) Termination.
IV. Venting (continued)
