BWT Manager Connect Duo User Manual

UNIVERS
12
2023/03 - Revision index: A - Code: 0000139233
3.3 Technical features
Features
Manager Connect Duo
pH/ORP
Manager Connect Duo
PH/ORP/Chlorine
Cabinet dimensions in mm
(Height-Width-Depth)
H: 210 x W:210 x D:130
H: 210 x W:210 x D:130
Mass
3.5kg
3.5kg
Power Supply
220-240 VAC 50-60 Hz
220-240 VAC 50-60 Hz
Power consumption (W)
28 Watt,
Equipped with galvanic insulation (ferrite)
28 Watt
Equipped with galvanic insulation (ferrite)
Relay outputs (3 or 4)
250 Vac 10A (resistive load)
250 Vac 10A (resistive load)
Fuse capacity
500 mA (Timed)
500 mA (Timed)
Display resolution
± 0.1 pH; ±10mV; ±1°C
± 0.1 pH; ±10mV; 0.1 ppm; ±1°C
Measurement accuracy
±0.02 pH, ±3 mV;±0.5 °C
±0.02 pH, ±3 mV; 0.05 ppm; ± 0.5°C
Measuring range
0-14 pH;
0 - 999 mV;
0…+55 °C
0-14 pH;
0 - 999 mV;
0-5 ppm (open cell);
0-10 ppm (closed cell);
0…+55 °C
Pump type
Peristaltic
Peristaltic
Pump flow rate (l/h)
1.5 l/h (pools) / 0.4 l/h (spas)
4 l/h
Maximum delivery pressure
1.5bar
1.5bar
Pump status
Pause - running
Pause - running
Waterproof-index of the cabinet
and the input/output connectors
IP 65
IP 65

BWT Manager Connect Duo Specifications

General

Brand	BWT
Model	Manager Connect Duo
Category	Controller
Language	English
