Dimensions of the wall mounting base in free-standing version:
Panel dimensions in pre-mounted version:
• Panel dimensions: 420 mm width x 700 mm height x 10
mm thickness
• Overall thickness: 150 mm
• Drilling centres: 390 mm x 670 mm
Main functions:
Possible control modes:
o Proportional
o Proportional TWM (Time Width Modulation)
o All or nothing
o "Boost"
Special operating mode:
o Clock
Simplified automated probe calibration with probe health diagnosis
Menu available in a choice of 7 languages
pH compensation of the water temperature
Inputs:
o Water temperature Probe
o Chemical shortage detector in storage tanks (pH corrector / chlorine disinfectant)
o Pump operation detection (1 per pump)
o Detection of water flow in the hydraulic network
Outputs:
o Audible and/or visual alarm
o Chlorine generator (electrolyser) control
Alarms:
o Overdose alarm
o Over threshold alarm
o Chemical tank end alarm (pH corrector / chlorine disinfectant)
