2023/03 - Revision index: A - Code: 0000139233
2B - Redox pump (ORP) submenu
2B1 SetPoint: target value for Redox potential
2B2 SetPoint Type :
ORP+: the pump is programmed to inject liquid chlorine and
increase the redox potential
ORP-: the pump is programmed not to inject anything, the
redox potential will drop by itself
2B3 OFA: "Over feed Alarm" = maximum continuous dosing time
before the alarm is triggered
2B4 ON time: duration of a pump injection sequence, adjustable
between 5 seconds and 3600 seconds (*)
2B5 OFF time: duration of a pump idle sequence,
adjustable between 5 seconds and 3600 seconds (*)
2B6 Alarm min : pH value below which the instrument goes into alarm
2B7 Alarm max : pH value above which the instrument goes into alarm
(* Time on and Time off are only available if set Type dosing settings= Timed)
2C - pump submenu CL
2C1 Setpoint : target value for free chlorine concentration
2C2 Type:
Cl+: the pump is programmed to inject liquid chlorine and
increase the free chlorine concentration value
Cl-: the pump is programmed not to inject anything, the
value of the free chlorine concentration will drop by itself
2B3 OFA: "Over feed Alarm" = maximum continuous dosing time
before the alarm is triggered
2B4 ON time: duration of a pump injection sequence, adjustable
between 5 seconds and 3600 seconds (*)
2B5 OFF time: duration of a pump idle sequence, adjustable between
5 seconds and 3600 seconds (*)
2B6 Alarm min : pH value below which the instrument goes into
alarm
2B7 Alarm max : pH value above which the instrument goes into alarm
(* Time on and Time off are only available if set Type dosing settings= Timed)
2D - Alarm Relay submenu
2F Alarm relay: allows you to choose which alarm will trigger a
device connected to input 9 on the cabinet:
• OFF: no activation
• Alarm: activation in case of OFA trigger, or Min alarm, or
Max alarm, or Flow check, etc.)
• Redox (ORP) (only in ON/OFF setting)
• Chlorine (only in ON/OFF setting)
_2B____Redox pump_____
► 1: Setpoint 700 mV
2: Type ORP +
3: OFA 00’
4: Time On 00’
5: Time Off 00’
6: Alarm min 600 mV
7: Alarm max 800 mV
01/07
_2F__Alarm Relay_____
► □ OFF
■ Alarm
□ Redox
□ Chlorine
01/03
_2C______CL Pump_____
► 1: Setpoint 1.2 ppm
2: Type Cl +
3: OFA 00’
4: Time On 00’
5: Time Off 00’
6: Alarm min 0.5 ppm
7: Alarm max 2.0 ppm
01/07
To Next Page
