4 Conguration
The following parameters for the Ethernet interface can only be accessed via the printer website:
Parameter Meaning Default
SMTP server E-mails can be sent to selected addresses when certain status and error
messages are generated. To activate:
Set parameter to "On".
Enter IP address of the SMTP server.
Enter a valid e-mail address for the printer in the "From address" eld.
More detailed information on sending e-mails “System messages tab" on page
25.
Off
Raw-IP port
Service for printing on the network ( ”2.2.1” on page 8).
Select a predened port address.
9100
LPD
Activation of the network printing service LPD ( ”2.2.1” on page 8):
Set parameter to "On".
Enter "lp" as the queue name.
Off
SNMP Data exchange between printer and management station via SNMP (Simple
Network Management Protocol). To activate:
Set parameter to "On".
Enter IP address of the management station(s) (receiver 1 or receiver 2).
Assign the "Community" parameter the value "public".
Off
Time server Synchronization of the date and time of the printer. To activate:
Set parameter to "On".
Enter IP address of the time server..
Synchronization occurs hourly. The accepted time is not automatically saved in the
printer, however. To save the accepted time:
Call up the parameter time and save the displayed setting with OK.
Off
Anonymous FTP Enables or disables a FTP-logon with as "Anonymous". On
12 Additional parameters for Ethernet interfaceTable
