5.5 Device List
Function not available at A2+ !
The Device list function prints out the most important information on hardware components of the printer and
connected devices. The printout occurs using the heat level and print speed specied in the Setup > Print
param. menu.
Notice!
The printout occurs without taking the label gaps into consideration. This is why endless media are most
suitable for this purpose.
Insert printable medium (labels, endless paper) which extends across the entire printing width.
If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
Press the menu button.
Select Test > Device list print menu.
Start printout with the button.
The printout can be cancelled with the cancel button.
Device list
Mach4/300 - 10/09/2007 -15:14:17
Firmware V3.11 (Aug 9 2007) - #111070553751
Name Description
CPU Thor, #111070553751
PCB-Rev. 7, CPU-Rev. 4
TPH 300 dpi, 1248 dots
I/F1 Ethernet 10/100 MBit/s
MAC: 00:02:E7:02:28:F4
I/F2 USB 2.0 Device
I/F3 RS-232
IFFS 8MB
USB [1] Generic/Generic Hub
[0] Full Rev. 3.00
Mfr: 03EB,Class: 09/00,Protocol: 00, Phase: 20/0
USB [2] cab/Service-Key
[1/1] Low #7-5037793,Rev. 1.05
Mfr: 0985,Class: FF/00,Protocol: FF, Phase: 20/4
USB [3] cab/Frontpanel
[1/3] Full Rev. 2.05
Mfr: 0985,Class: FF/1C,Protocol: 00, Phase: 20/1
abc licensed under Artistic license from Yabasic 2.715 (www.yabasic.de)
CMU-SNMP © 1988-89 Carnegie Mellon University,© 1995 Glenn Waters
jTreeTable © 1997-1999 Sun Microsystems, Inc. All Rights Reserved
Portions of this software are © 2005 The FreeType Project
(www.freetype.org). All rights reserved.
mDNSResponder © 2002-2006 Apple Computer Inc. All Rights Reserved
Licensed under the Apache License, Version 2.0
13 Device listFig.
Name Information
CPU Type and serial number of the CPU PCB
Revision of CPU PCB and CPU
TPH Resolution and heating point number of the installed thermal printhead.
IF [x] Type of interfaces installed
x: Number of interface
IFFS Size of the Internal Flash File System
CF / CFEXT /
PCCARD / USBMEM
Size and type of an installed external memory medium
USB [a]
[b/c] Speed
Type and revision of installed USB devices
a: number of USB device
b: number of USB device to which device a is connected
c: number of interface of device b to which device a is connected
Speed: data transfer speed (low, full, high)
The following properties are only displayed when the service key is inserted:
Mfr.: Manufacturer ID. This identies the manufacturer of the USB device
Class: Code for the USB device class
Protocol: Code for the type of communication with the USB device
Phase: Internal value for troubleshooting
17 Parameters of the Device listTable
