5 Test Functions
5.1 Overview
The printer is equipped with different test functions providing information on:
the most important conguration parameters
the fonts available in the printer
important hardware components and connected peripheral devices
the print image quality and state of the thermal printhead
the function of label detection in conjunction with the optical properties of the label medium
the label data sent from the computer or read out from the memory medium
5.2 Short Status
The Short status menu provides an overview of important status information in the display of the printer.
Press the menu button.
Select Short status menu.
Scroll through the individual lines with the ~ and buttons.
Exit the Short status menu with the button.
The following conguration parameters are displayed in the Short status menu:
Line Meaning Example
1 Printer type
MACH4/300
2 Version number of the printer operating system (rmware)
Firmware V3.11
3 Creation date of rmware
(Aug 9 2007)
4 Version number of the system loader (bootloader)
Bootloader 1.18
5 Creation date of the bootloader
(May 29 2007)
6 Serial number of the PCB CPU
PCB #111070553751
7 Revision of the CPU PCB and the CPU
PCB/CPU Rev. 7/4
8 Operative time and number of printed labels
Hours/no. of labels:
156h/3564
9 Previously printed paper lengths with thermal direct printing / thermal
transfer printing
Thermal/Transfer
13,54m/269,11m
10 IP address of the label printer when connected to a network
DHCP-IP 192.168.9.13
11 mDNS name of the printer for Zeroconf (Zeroconf is a set of techniques that
automatically create a usable IP network without conguration or special
servers.)
mDNS: cab-28154.local
12 MAC address of the network adapter on the CPU PCB
MAC 0002E70228F4
13 Type and size of the installed memory medium
CF 30MB
14
Size of the Internal Flash-File-Systems ( Programming Manual)
IFFS 8MB
15 Resolution of the installed thermal printhead
TPH 300dpi,1248dots
14 Display in Short status menuTable
•
•
•
•
•
•
