LEGEND Fig. 24
1 45,6 cm
2 97 cm
3 50,6 cm
4 20,8 cm
5 32,4 cm
6 13,8 cm
7 Hole combustion air inlet d.6 cm
8 Exhaust fumes d.8 cm
9 17,9 cm
Fig. 25 - General dimensions: Pretty Airtight
LEGEND Fig. 25
1 51 cm
2 97 cm
3 50,7 cm
4 20,8 cm
5 32,4 cm
6 16,9 cm
7 Exhaust fumes d.8 cm
8 Hole combustion air inlet d.6 cm
9 20,9 cm
