Technical data
Power supply
Alternating voltage 230 V / 50 Hz, single-phase
Range approx.180 V – 264 V / 50 – 60 Hz
Output current (Battery 2 charging current)
Charging current max. 16 A, arithmetic average, electronically
regulated according to the charging characteristic curve IUoU.
Output current (Battery 1 charging current)
When the battery potential of battery 2 reaches 14.1 V, a par-
allel connection is established with battery 1. Compensating
current dependent on the charge state of battery 1 (starter
battery). If the voltage of the battery 2 drops below 13.0 V, the
parallel circuit is automatically disconnected.
Output voltage
Direct voltage 12 V
Charging process
Automatic
Automatic switching (Bulk phase)
OFF when battery voltage reached 14.4 V,
charging current < 16 A.
Automatic switching (Absorption phase)
Ten hours at a constant 14.4 V for gel or AGM batteries.
Four hours at a constant 14.4 V for liquid electrolyte batteries.
Automatic switching (Float phase)
Float phase, constant at 13.8 V
Temperature dependent control (optional)
The values of the automatic switching refer to a battery
temperature of 20 °C. When using a temperature sensor at
the battery 2, these values vary as a function of the battery
temperature.
High temperature –> Lowering of the threshold values.
Low temperature –> Higher threshold values.
Application
Parallel operation, buffer operation, general charging operation.
Temperature
Ambient temperature of -25 °C to +35 °C.
During operation, the housing may heat up to approx. 75 °C.
Cooling
By convection.
Implementation
According to Association of German Electrotechnical Engineers
regulations and the provisions of the Instrument Safety Act.
Test labelling
Use
For charging batteries with a rated voltage of 12 V and a
capacity of 50 – 160 Ah.
Dimensions / weight
Housing
Aluminium, ventilated
Length
275 mm
Width
190 mm
