MENU DESCRIPTIONS
MAIN MENU SUB MENU DESCRIPTION
FUNCTIONS (continued...) The functions menu determines how your operator will function.
Lamp E E Lamp: Setting up the flashing light or cycle lamp or courtesy lamp connected on 10-E:
- Courtesy Light: Outdoor lamp that can be freely positioned, for additional lighting of the driveway - stays on for 5 minutes.
- Cycle: Outdoor lamp, which can be positioned at leisure, for better illumination in the parking/driveway area. The light stay
s on from
the moment the gate begins to open, until it is fully closed (including automatic closing time).
If the automatic closing function is not enabled, the light stays on only during gate movement.
- Flashing Light: Signals the gate opening or closing movement.
Output B1-B2
B1-B2 Output: S
etting contact B1-B2 to MONO-STABLE or BI-STABLE (switch) mode.
Imp. Run Gate-Run Setting Menu
No. Motors
Number of Motors: Set the number of motors, either one or two, depending on the number of gate(s) installed on the system (M1 &
M2 setting is for dual gates, M2 is for single gate).
Motor type
Motor Type: Select FROG for the motor type.
High Speed %
% Speed of Action: Setting up the speed during gate operation, expressed as a percentage between 20% and 100%.
Low Down Spd
% Speed of Deceleration: Setting up the deceleration speed, expressed as a percentage between 5% and 50%.
Soft Start
Delayed Start: A
fter an open or close command, the gate(s) start at a slow speed for a few seconds.
Sens. Amperom
Amperometric Sensitivity: T
he level of gearmotor sensitivity in the face of obstacles during operation.
When the amperometric sensitivity is on, and an obstacle is detected, depending on the configuration, the gearmotor works in the f
ollowing
ways:
- timed endpoint: it stops while performing a gate run;
- end point: it inverts direction of travel during operation;
- decelerations: it inverts direction of travel during operation, while during the deceleration phase it stops;
- Fcap-RallCh.: it inverts direction of travel during operation, while during the deceleration phase it only stops when on a closing run.
When the amperometric sensitivity is off, and an obstacle is detected, the gearmotor stops when the maximum current threshold is
exceeded (i.e. overload).
NOTE: T
his function appears only if the “encoder” function is not selected in the FUNCTIONS menu.
Run Amperom
Gate Run Amperometrics: Setting the gearmotor sensitivity in the presence of obstacles.
NOTE: This function only appears if the amperometric sensitivity is selected (not with encoder configuration).
Slow down time Deceleration Time: Gate leaf deceleration time before each endpoint. The time can be set anywhere between 0” to 30”.
NOTE: T
his function only appears if the decelerations and Fcap-RallCh. are selected.
TIMING ADJ. Time setting menu
ACT
Automatic closing: To set the waiting time when gate is in the open position. Once this time is elapsed, the gate closes automatically.
The waiting time can be set to between 0” and 300”.
Partial ACT
Automatic Partial Closing: Waiting time of the (M2) second gate when in the open position. Once this time interval has elapsed, the
gate automatically closes. The waiting time interval can go anywhere from 0” to 300”.
Cycle Time
Cycle Time: The working time of the motor during opening or closing phases is anywhere from 10” to 150”.
Op. Delay M1
M1 Delayed Opening: The waiting time of the (M1) first gate lead, unlike the (M2) second one, after each opening command. The
waiting time can be set to between 0” and 10”.
CI. Delay M2
M2 Delayed Closing: The waiting time of the (M2) second gate leaf, unlike the (M1) first one, after each closing command.
The waiting time can be set to between 0” and 60”.
Lock Time
Lock Time: The time required for releasing the electro-lock after each opening command. The time of operation can be set to between 1”
and 5”.
Ram hit time
Ram blow time: The gearmotorʼs thrust time when fully closing and opening after each command .The thrust time can be set to between
1” and 3”.
Slow down time Partial Opening: Opening time of the second (M2) gate leaf. The time can set between 5 and 60 seconds.
PROGRAMMING
