Keyword Information and Location
PCAP
PCAP is a packet capture (PCAP) file of network packet data (network
traffic) that can be opened by Wireshark. This setting specifies the
network interface, file name, and maximum size of the PCAP file. For
example:
l "usr:debug.pcap" saves the file to the USRdrive with the file type
.pcap.
l ".ring." found in name will create new files once the file size has
been reached. "crd:debug.ring.pcap" creates crd:debug001.pcap,
crd:debug002.pcap...
l If a number follows .ring. then only that number of files will be
saved, with the oldest deleted. For example:
"usr:debug.ring.3.pcap" will save three files.
If All Networks is selected as the Network Interface and PPP/Cell is
active, then seperate files will be opened for the PPP/Cell network with
"ppp." prefixed on the file name.
Where to find:
l Settings Editor tab in Device Configuration Utility: Advanced |
PCAP Network Interface, PCAPFile Name, PCAP File Size
9. Tips and troubleshooting 153
