Canon DC20 E - BACK END MI-COM Input Port

DC10 E, DC20 E
SERVICE MODE / ADJUSTMENT
11
4-4-5 BACK END MI-COM Input Port
PIN NAME Description CS Function ADDR
DAT
A
BIT
DESCRIPTION
T3 AV DET Multi terminal connection detect 0 01 000B 5 "H" at detect
T5 PANEL Open Switch LCD open detect 0 01 000A 2 "H" at the open
