DC10 E, DC20 E
GENERAL DESCRIPTION OF PRODUCT
16
2-2-2 Main Mechanical Parts
Fig. 3
Spindle motor Control board
Cover
Material of lens
protection
Coil wiring material
Coil wiring material
Coil wiring material
Suspension
Closeup of Pick-up
Pick-up Tracking motor
Suspension
Magnet
Magnet
