SERVICE MODE / ADJUSTMENT
13
○
: Adjustment required
Camera system
Part name
No. Adjustment item
Lens
GYRO
PCB
CCD
PCB
MAIN
PCB
Adjustment setting
5-6 Camera Section
5-6-1 Iris Adjustment
○○○
Product condition
5-6-2 WB Adjustment (1)
○○○
Product condition
5-6-3 Color Balance Adjustment
○○○
Product condition
5-6-4 WB Adjustment (2)
○○○
Product condition
5-6-5 WB Adjustment (3)
○○○
Product condition
5-6-6 DATA Writing
○○○
Product condition
5-6-7 CCD Pixel Missing Compensation
○○
Product condition
Recorder system
Part name
No. Adjustment item
MAIN
PCB
T
S
mech
chassis
LCD
PCB
Adjustment setting
5-7 Recorder Section
5-7-1 Playback error rate check
○○
Product condition
5-7-2 Self-recording error rate check
○○
Product condition
5-7-3 LCD PCB Setting Destination
○
Product condition
