DC10 E, DC20 E
SERVICE MODE / ADJUSTMENT
35
Error Code Table for CCD Pixel Missing Compensation (DC20 E)
In the DC20 E, if a pixel missing is found on the CCD pixels, it is required to scan each of the RG and GB images. Therefore, white
dot detection is performed twice, and the result of the detection is indicated on a bit basis.
Fig. 23
ERROR No
Total of white dots
STATUS CODE
(ST)
Error No Error Conditions
00 Normal end
10 The number of white dots has exceeded the upper limit in the first time of detection
20 The number of white dots has exceeded the upper limit in the second time of detection
40
The total number of white dots in the first time and second time of detection has exceeded the upper limit
80 In white dot detection, three consecutive missing pixels in a row are detected.
