Canon imagePRESS Lite C170 Series Service Guide
imagePRESS Lite C170 Series Service Guide March 2022
Revision 11 Page 102
Table 65 – Booklet Finisher-W1 PRO and Staple Finisher-W1 PRO
Specifications Continued
Item
Specifications
Maximum Stapling
Capacity/Available
Staple Size
(Corner/Double)
LTR and EXEC
100 sheets (20 lb bond (80 g/m
2
)) or below 1/2" (11 mm) in height,
98 sheets (20 lb bond (80 g/m
2
)) + (2 cover sheets up to 140 lb
index (256 g/m
2
))
11" x 17", LGL and LTRR
50 sheets (20 lb bond (80 g/m
2
)) or below 1/4" (5.5 mm) in height,
48 sheets (20 lb bond (80 g/m
2
)) + 2 cover sheets up to 140 lb
index (256 g/m
2
))
Corner Stapling:
11" x 17", LGL, LTR, LTRR, EXEC, and Custom Size (8 1/4" x 7
1/8" to 11 3/4" x 17" (210 mm x 182 mm to 297 mm x 432 mm))
Double Stapling:
11" x 17", LGL, LTR, LTRR, EXEC, and Custom Size (7 1/8" x 7
1/8" to 11 3/4" x 17" (182 mm x 182 mm to 297 mm x 432 mm))
Puncher Unit-BS1
(When the puncher unit is
attached)
Paper Sizes:
• 2 Holes: 11" x 17", LGL, LTRR, LTR, EXEC, and Custom Size
(7 1/8" x 7 1/8" to 11 3/4" x 17" (182 mm x 182 mm to 297 mm x
432 mm))
• 3 Holes: 11" x 17", LTR, EXEC, and Custom Size
(9 1/2" x 7 1/8" to 11 3/4" x 17" (240
mm x 182 mm to 297 mm x
432.0 mm))
Paper Weight: 14 lb bond to 110 lb cover (52 g/m
2
to 300 g/m
2
)
Punch Holes: 2/3 Holes
Puncher Unit-BT1
(When the puncher unit is
attached)
Paper Sizes:
• 2 Holes: LGL, LTRR, and Custom Size (7 1/8" x 7 1/8" to 11
3/4" x 17" (182 mm x 182 mm to 297 mm x 432 mm))
• 4 Holes: 11" x 17", LTR, EXEC, and Custom Size
(10 1/8" x 7 1/8" to 11 3/4" x 17" (257 mm x 182 mm to 297 mm
x 432 mm))
Paper Weight: 14 lb bond to 110 lb cover (52 g/m
2
to 300 g/m
2
)
Punch Holes: 2/4 Holes
Saddle Stitch/Fold
(Booklet Fininsher-W1
PRO Only)
Size
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTRR, and
Custom Size 8 1/4" x 11" to 13" x 19 1/4" (210 mm x 279.4 mm to
330.2 mm x 487.7 mm)
Cover Weight
Requires the paper weight of the main document (more than 17 lb
bond (64 g/m2)) or more.
(Available Saddle Stitch capacity may vary, depending on the paper
type and weight.)
Saddle Stitching Capacity (including 1 cover sheet)
• 25 sheets (20 lb bond (80 g/m²))
Maximum Saddle Folding Capacity
• 5 sheets (20 lb bond (80 g/m²))
