Canon imagePRESS Lite C170 Series Service Guide
imagePRESS Lite C170 Series Service Guide March 2022
Revision 11 Page 101
Table 65 – Booklet Finisher-W1 PRO and Staple Finisher-W1 PRO
Specifications
Item
Specifications
Paper Size/Weight/Type
84
Size
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTR, LTRR,
EXEC, STMTR, Custom Size (3 7/8" x 5 7/8" to 13" x 19 1/4" (98.4
mm x 148 mm to 330.2 mm x 487.7 mm)), and Envelopes
Notes:
• With the Long Sheet Catch Tray-
A1 the sheet length is from 19.2” to 51
1/4" (487.8 mm x 1,300 mm). Long sheets can only be output to Tray A.
• With the Long Sheet Feeding and Catch Tray-B1/C1 attached, the
custom size is from
3 7/8" x 5 7/8" to 13"
x 51 1/4" (98.4 mm x 148 mm to 330.2 mm x 1,300
mm).
Long sheets can only be output to Tray A. To use long sheet, press
[Function Settings] > [Common] > [Paper Output Settings] > [Output
Tray Settings] (Settings/Registration), and then set the output
destination to [Tray A]. (Long sheets between 30” up to 51” require
manual handling to retrieve printed sheets from the finisher.)
Weight
Weight: 14 lb bond to 130 lb cover (52 to 350 g/m
2
)
Type
Thin, Plain, Heavy, Color, Recycled, Pre-Punched, Transparency,
Tracing, Labels, Tab, Bond, Letterhead, and Coated, Textured,
Vellum and Envelopes
Capacity Per Tray
88
(Tray A)
No Collating/Collate/Group/Offset mode
• 1,000 sheets (or 5 3/4" (147 mm) in height)
• With the Long Sheet Tray
o 19.2” to 30” (487.8 mm to 762.0 mm): 50 sheets (80 g/m
2
)
• With the Long Sheet Catch Tray XL-A1
o 19.2” to 30” (487.8 mm to 762.0 mm): 300 sheets
o 30” to 51.2” (762.1 mm to 1300 mm): 50 sheets
Z-Fold mode (when the Paper Folding Unit-J1 is attached)
• 11" x 17": 30 sheets
Half Fold mode (when the Paper Folding Unit-J1 is attached)
• LTRR: 50 sheets
Capacity Per Tray
88
(Tray B)
No Collating/Collate/Group/Offset mode
If the High Volume Stack Mode is set to 'Off'
• LTR and EXEC: 2,000 sheets (or 11 1/4" (285 mm) in height)
• All other combinations: 1,000 sheets (or 5 4/3" (147 mm) in
height)
If the High Volume Stack Mode is set to 'On' (The maximum stack
volume may vary, depending on the paper type.)
• LTR and EXEC: 4,000 sheets (or 19 1/4" (490 mm) in height)
• LTRR: 2,000 sheets (or 11 1/4" (285 mm) in height)
• 11" x 17" and LGL: 1,500 sheets (or 8 1/2" (216 mm) in height)
• 13" x 19", 12 5/8" x 17 11/16", and 12" x 18":
1,500 sheets (or 8 1/2" (216 mm) in height)
Staple mode
• LTR and EXEC: 200 sets (or 19 1/4" (490 mm) in height)
• LTRR: 200 sets (or 11 1/4" (285 mm) in height)
• 11" x 17" and LGL: 200 sets (or 8 1/2" (216 mm) in height)
Z-Fold mode (when the Paper Folding Unit-J is attached)
• 11" x 17": 30 sheets
84 Reference Registered Paper Types and Weight for the available paper weights.
88 To stack 2,000 sheets or more LTR paper, use Tray B first, and then use Tray A for outputting paper.
