Table 42 – Reader / ADF Periodic Maintenance Items
Periodic Maintenance
Part Name
Estimated
Interval
68
Action Remarks
Reader
Front and back sides of
Copyboard Glass (Large)
As necessary Clean
Clean when soiling is remarkable
(including the back side White Plate)
Front and back sides of
Copyboard Glass (Small)
As necessary Clean
Scanner Rail As necessary
Clean /
Lubricate
ADF
Post-separation Sensor 1
160,000 sheets or
12 months
Clean
- Photo sensor only
- Cleaned at an interval of the actual
number of sheets fed
Post-separation Sensor 2 Clean
Post-separation Sensor 3 Clean
Lead Sensor Clean
Registration Sensor Clean
Delivery Sensor Clean
Double Feed Detection Sensor
(Transmission side)
Clean
Double Feed Detection Sensor
(Reception side)
Clean
Registration Roller
80,000 sheets or
6 months
Clean
Lead Roller 1 Clean
Lead Roller 2 Clean
Lead Roller 3 Clean
Pullout Roller Clean
Feed Roller Clean
Delivery Roller Clean
Rollers, Slave Roller Clean
Scrapers Clean
Both sides of the back Platen
Glass (built in the ADF)
Clean
ADF height adjustment Adjust
68 Value is based on LTR sized paper. Estimated average values in the field, based on data from
supplier. Data is subject to change depending upon many factors including, without limitation,
monthly copy volume, environment, type of image printed and customer handling of the equipment.
